Battery and inverter
16 kWh LiFePO4 battery with a 12 kW inverter.
TRESUN-TECH · All-In-One Home Energy Storage
AIO-1P12K16-plus
16 kWh LiFePO4 battery and 12 kW inverter in a standing all-in-one home energy storage system with integrated PV and AC charging.
- 16 kWh Energy
- 12 kW Inverter
- 51.2 V / 314 Ah
- IP20
LiFePO4Battery + Inverter
PV + ACIntegrated Charging
UPSIntegrated Function
System Overview
Standing all-in-one ESS
LiFePO4 battery storage, inverter, PV charging, AC charging and UPS function in one residential energy system.
PV and AC charging
Integrated PV input and AC charging.
Integrated UPS
UPS function for residential energy storage.
Available Configurations
All-in-one home ESS models
10.5 kWh + 6 kW · 16 kWh + 6 kW · 16 kWh + 12 kW
Residential Energy Storage
Integrated residential energy storage
- 01
- LiFePO4 battery storage
- 02
- 12 kW inverter
- 03
- PV and AC charging
- 04
- Integrated UPS function
Product Positioning
AIO-1P12K16-plus
- System type
- All-In-One ESS (Standing)
- Battery chemistry
- LiFePO4
- Battery voltage
- 51.2 V
- Rated capacity
- 314 Ah
- Energy
- 16 kWh
- Inverter power
- 12 kW
- MPPT voltage range
- 60-450 Vdc
- AC voltage
- 230 Vac
- IP grade
- IP20
- Communication
- RS485 / WiFi
- Dimensions
- 510 × 377 × 770 mm
- Weight
- Approximately 120 kg
Project Enquiry
Request AIO home storage pricing
16 kWh LiFePO4 battery · 12 kW inverter · 230 Vac · IP20
Product model
AIO-1P12K16-plus
