Modular expansion
Wall-mounted units support parallel operation up to 15 pieces, subject to final system design. The related stackable 16 kWh base stacks 2 to 5 modules.
AINEGY · Residential LiFePO4 Battery
16 kWh LFP Battery
Wall-mounted 51.2 V LiFePO4 battery for home solar storage and backup. Catalogue energy 16 kWh at 314 Ah (16.08 kWh at 51.2 V x 314 Ah). Battery only; inverter and enclosure rating are confirmed with the selected housing.
- 16 kWh / 16.08 kWh
- 51.2 V / 314 Ah
- 200 A max. current
- LiFePO4
LiFePO4Battery only
51.2 V314 Ah / 200 A
RS485 / CANBMS communication
System Overview
Wall-mounted 16 kWh LFP battery
Residential 51.2 V LiFePO4 battery for pairing with a compatible hybrid or off-grid inverter. Not an all-in-one ESS: no integrated PV charger, AC charger or UPS in this SKU.
LiFePO4 chemistry
Natural-cooling 51.2 V platform. Current limit and protection rating are confirmed with 16kWh/A1 or the stackable 16 kWh housing.
BMS communication
RS485 / CAN for inverter and EMS integration. Any monitoring app depends on the paired inverter and is confirmed at quotation.
Available Configurations
16 kWh LFP housings
16kWh/A1 · Stackable 16 kWh base · 10kWh/A1 family option
Residential Energy Storage
Home solar storage and backup
- 01
- LiFePO4 battery storage
- 02
- 51.2 V / 314 Ah platform
- 03
- Wall-mount or stackable housing
- 04
- RS485 / CAN communication
Product Positioning
16kWh/A1
- System type
- Residential LiFePO4 battery (wall-mounted)
- Battery chemistry
- LiFePO4
- Catalogue energy
- 16 kWh
- Energy at 51.2 V x 314 Ah
- 16.08 kWh
- Battery voltage
- 51.2 V
- Rated capacity
- 314 Ah
- Max. current
- 200 A
- End-of-charge voltage
- 58.0 V
- End-of-discharge voltage
- 42.0 V
- Communication
- RS485 / CAN
- Thermal architecture
- Natural cooling
- Parallel operation
- Up to 15 units, subject to final system design
- Dimensions
- 850 x 420 x 230 mm
- Weight
- about 105 kg
- IP grade
- Confirm with selected housing
- Cycle life
- Confirm on the quotation-stage datasheet
Project Enquiry
Request 16 kWh LFP battery pricing
16 kWh LiFePO4 · 51.2 V / 314 Ah · 200 A · RS485 / CAN
Product model16kWh/A1
